CAD (Cardboard Aided Design)

I know that I’m not the first one to come up with the idea, but much like graph paper is cheaper than lumber, cardboard is cheaper than any other building materials; especially when you keep your empty cereal boxes.

I’ve got this metal parts organizer in the garage. The biggest problem with it is that stuff gets lost in the back. I decided to make bins so I could easily get everything out. The perfect material would be sheet metal, but I’ve never worked with sheet metal before. Enter CAD.

I’ve made three prototypes, and finally got my design where I want it. My out of pocket expense is, some blue tape, three empty cereal boxes and a utility knife blade, so zero dollars. Now it’s time to get some metal and start making bins.

In the past, I’ve used cereal boxes & tape to dummy up lots of projects. The original camp kitchen idea was done in cardboard. This exercise proved that the vision I came up with while high was not something I could achieve and led to the simpler version that I originally built from wood.

I always keep a few empty boxes in the shop, you never know when you’re going to mock something up.

The Royal has no clothes.

Made some more progress on the Model 10.

Got the front panel and rear top panels off. Got the carriage out. It appears that the sides & rear are one piece of iron, so I don’t think there are any more covers to remove.

I got the type bars to travel the full stroke!

No more covers to remove.

Once I removed the carriage, I confirmed that the far end of the draw band is missing, so I’m adding that to the list of parts I need to source.

Continue reading “The Royal has no clothes.”

First real look at the Royal

Got my bench cleared off and put the Royal up. Actually took my first real good look at the entire unit today.

Remember, I originally bought it for the key caps only.

I vacuumed the entire unit and closely examined it and things (as usual) got more complicated than expected.

Can I interest you in an off-color joke about “not going down”?
Continue reading “First real look at the Royal”

Sometimes it’s the little things

I love this sharpener

Back in the days when I maintained foreclosed homes, I saw these installed in basements all over Philly. They never had the outer can, just the grinders, so I left them there. I finally broke down and bought one, and couldn’t possibly be happier.

Continue reading “Sometimes it’s the little things”

Modifying the utility trailer

Last year I bought a utility trailer. Mostly because I was tired of putting Yurt bits on the roof of the Excursion. But also because I knew I was going to need to haul things I didn’t want inside my baby.

Today, I needed to hail a cubic yard of gravel, but the open sided utility trailer was just the wrong tool for the job.

I think I’d get home with almost zero gravel.
Continue reading “Modifying the utility trailer”

The Power of Iterative Engineering

Or, don’t let the perfect be the enemy of the good.

I’m an over planner. There’s no arguing it.

My very first boss drilled into my head “We never have time to do it right, but we always have time to do it again.”

Continue reading “The Power of Iterative Engineering”
